Helical geared motor
Features

• High range of transmission ratios (plug-on pinion)
• Very economic performance
• Very energy efficient (efficiencies of 98 % per stage)
• High power range

Mechanical construction

• Stages: 1, 2 or 3
• Mounting types: foot-mounted and flange-mounted designs, housing flange
• Shaft design: solid shaft

Transmission stages

• 2-stage or 3-stage helical geared motors
• 1-stage helical geared motors for high output speeds
• 4-stage to 6-stage helical geared motors for very low output speeds

Typical applications

• Conveyor belt
• Transport of packaged goods
• Vertical conveyor
